Post subject: Titanium v6.2.1 on latest version of GNS3 & VB.

Hello everyone,
Able to run Titanium v6.2.1 on GNS3 with VB with some limitations..Please note, there are some issues with this image also, before proceeding, scroll-down and read issues.
These instructions assume you know the basics of using GNS3 and the VirtualBox installation and configuration process.
Credits go to everyone that has helped out in any way in the GNS3, Titanium, Virtualbox.., and particularly the many gurus on this forum.
!
1. Download and install the latest version of:
- GNS3
- VirtualBox & extensions
2. Download the files (there are 3 files) and extract the files.
file 1: http://bit.ly/1dbJikB
file 2: http://bit.ly/1gpb5SK
file 3: http://bit.ly/18YTIbt
Password to extracting the files: GNS3
HASH for the first file:
MD5: B881141A3933CCD4B28C4710552DF154
SHA-1: 8ED72355289C2BE5CA5B8342EFC873ED1EFD87D7
Misc. Tools:
Get HASHTAB @ http://implbits.com/HashTab.aspx
7 zip : http://www.7-zip.org/ or winrar : http://www.rarlab.com
!
3. Start VirtualBox
Add 1st VB Machine:
> From top menu > select 'Machine' > select 'Add' > located the extracted folders, select 'location_of_folderTitanium-v6.2.1Titanium-v6.2.1.vbox'
Add 2nd VB Machine:
> From top menu > select 'Machine' > select 'Add' > located the extracted folders, select 'location_of_folderTitanium-v6.2.1-vb2Titanium-v6.2.1-vb2.vbox'
4. Start GNS3
1. Update VirtualBox Preferences:
> From top menu > select 'Edit' > select 'Preferences' >
> From Preference Page > select 'VirtualBox' > select 'VirtualBox Guest' tab
Identifier name : Tv6.2.1-lab1 (or some name)
VM List : click dropdown and select 'Titanium-v6.2.1'
Number of NICs : 6 (module 2 has 9 ports assigned)
Check the first 3 check boxes. Note: First box allows you to communicate with your LAN/LAB..
2. Repeat the above steps for the 2nd VB Machine 'Titanium-v6.2.1-vb2'
3. Create topology
2 * VBoxDevice
1 * router (37xx with NM-16 ..)
*** Note: each VB Machine uses 2G RAM!!! If you have less than 4G RAM, you may want to run single VB Machine at a time..
!
Issues:
Not able to run LACP
Not able to configure peer-link
Not able to change interface from L3
Not able to remove ports from VDC
Able to create portchannel, but not able to assign to interface/s..
Able to ping connected interfaces other than N7Ks
!
N7K-1(config)# feature lacp
Error
!
not able to associate po x to an interface
interface port-channel2
no switchport
ip address 172.17.1.2/30
!
N7K-2(config-if)# channel-group 2 mode on
Please check if command was successful using appropriate show commands
!
!
Here's some output:
!
N7K-1(config)# sh int status
--------------------------------------------------------------------------------
Port Name Status Vlan Duplex Speed Type
--------------------------------------------------------------------------------
mgmt0 -- connected routed full 100 --
Eth2/1 -- connected routed full 1000
Eth2/2 -- connected routed full 1000
Eth2/3 -- notconnec routed auto auto
Eth2/4 -- disabled routed auto auto
Eth2/5 -- notconnec routed auto auto
Eth2/6 -- disabled routed auto auto
Eth2/7 -- disabled routed auto auto
Eth2/8 -- disabled routed auto auto
Eth2/9 -- disabled routed auto auto
!
N7K-1# sh run | b feature
feature telnet
cfs eth distribute
feature pim
feature eigrp
feature interface-vlan
feature hsrp
feature vpc
!
N7K-1# sh run vdc
!Command: show running-config vdc
!Time: Wed Jan 1 22:13:39 2014
version 6.2(1)
vdc N7K-1 id 1
limit-resource module-type m1 f1 m1xl m2xl f2e
allocate interface Ethernet2/1-9
limit-resource vlan minimum 16 maximum 4094
limit-resource vrf minimum 2 maximum 4096
limit-resource port-channel minimum 0 maximum 768
limit-resource u4route-mem minimum 96 maximum 96
limit-resource u6route-mem minimum 24 maximum 24
limit-resource m4route-mem minimum 58 maximum 58
limit-resource m6route-mem minimum 8 maximum 8
N7K-1#
!
N7K-1(config)# dir
16384 Jan 07 00:54:26 2011 lost+found/
26387 Jan 01 21:59:33 2014 mts.log
4096 Dec 31 14:38:12 2013 scripts/
28511744 Dec 23 02:21:57 2010 titanium-d1-kickstart.5.1.2.gbin
28651520 Dec 31 14:32:55 2013 titanium-d1-kickstart.6.2.1.bin
60024194 Dec 23 02:22:00 2010 titanium-d1.5.1.2.gbin
80582117 Dec 31 14:34:27 2013 titanium-d1.6.2.1.bin
4096 Jan 07 00:55:10 2011 vdc_2/
4096 Jan 07 00:55:10 2011 vdc_3/
4096 Jan 07 00:55:10 2011 vdc_4/
292 Dec 31 16:10:00 2013 vlan.dat
!
Software
loader: version N/A
kickstart: version 6.2(1)
system: version 6.2(1)
kickstart image file is: bootflash:///titanium-d1-kickstart.6.2.1.bin
kickstart compile time: 12/25/2020 12:00:00 [04/10/2013 13:40:25]
system image file is: bootflash:///titanium-d1.6.2.1.bin
system compile time: 2/21/2013 10:00:00 [04/10/2013 18:19:27]
!
Please help each other and Happy Lab Time :-)
Cheers!

Post subject: Re: Titanium v6.2.1 on latest version of GNS3 & VB.

hi
thease files cannot be download due to Department of telecome of india has blocked the upload file server site please share a torrent link for the same .
file 1: http://bit.ly/1dbJikB
file 2: http://bit.ly/1gpb5SK
file 3: http://bit.ly/18YTIbt
Password to extracting the files: GNS3
regards
ashok

Post subject: Re: Titanium v6.2.1 on latest version of GNS3 & VB.

that's not fair..
1. try this: google it for 'uploaded generator premium' and from search result, select something like simpleleech, rapid8 ..etc.
2. does the proxy services work, e.g. http://www.hidemyass.com, http://www.proxy4free.com ..
if you still have problem downloading it, send me PM.
Cheers!

Post subject: Re: Titanium v6.2.1 on latest version of GNS3 & VB.

I am unable to extract the files. The password given does not work. Any help is greatly appreciated.

Post subject: Re: Titanium v6.2.1 on latest version of GNS3 & VB.

I've just extracted the files using GNS3 with WinRAR.

Post subject: Re: Titanium v6.2.1 on latest version of GNS3 & VB.

and

oglumavd, this seems like a great contribution. but using the .rar format is the worst archiving choice ever.

Post subject: Re: Titanium v6.2.1 on latest version of GNS3 & VB.

This is a great by the way. I followed the instructions exactly as shown. It boots just fine, however I end up in 'switch(boot)' mode. When I run an init system check-filesystem though I get the following: 'There is a problem with the compact flash. It could not be initialized.' Anyone have any ideas??

Post subject: Re: Titanium v6.2.1 on latest version of GNS3 & VB.

How can I console in on the titanium in gns3. Name piped option doesn't work.

Post subject: Re: Titanium v6.2.1 on latest version of GNS3 & VB.

how do you connect titanium to gns3 using putty. Name piped seems not to work. I tried using gns3 and virtualbox.

Post subject: Re: Titanium v6.2.1 on latest version of GNS3 & VB.

can somebody help me to download this file coz i found issue while downloading from uppload.net.its block from my ISP or many other ISP pls upload file on either 4shared or any other place
